Royal - 75 Lb (97.5") Digital Thermostat High Efficiency Fryer with Built In Filter and Solid State Control Temperature Readout (5 Tanks) - RHEF-75-5-DM
Model Number: CELC-RHEF-75-5-DM
Description
The Royal RHEF-75-5-DM is the ideal solution for kitchens that require efficient frying operations while maintaining the highest standards of cleanliness and food quality. The fryer's tank assembly has a capacity ranging from 75 to 85 pounds of oil, providing ample space for frying. The fryer has casters for easy movement, allowing for flexibility in kitchen setup and maintenance.
Standard Features:-
- Fully welded frame with 2 year warranty
- 72% Energy Efficiency
- “Zero” Recovery time
- 129 lbs. per hour production capacity
- 75-85 lb capacity stainless steel tank assembly
- 17-1/2” X 18” frying area
- Innovative heat exchanger assembly transfers maximum heat to the oil
- 4 tube heat entry with easily removable diffusers reduces thermal stress
- Automatic pilot ignition with 100% safety
- High efficiency in-shot burners rated at 33,000 BTU/hr each
- Extremely low exhaust flue temperatures
- Shortening return through the wash down hose
- Twin fry baskets with plastic coated handles for ease of handling
- 1¼” full port drain valve
- Casters
- 25 sheets of filter paper
- Ten year limited (prorated) warranty on S/S tank
Option and Accessories:
- Royal Plus Filtration- Shortening returns thru the bottom of tank
- Royal Ultra-Plus Filtration- Shortening returns thru the bottom of tank and thru the wash hose
- SDS- Rear oil disposal port
- Fine mesh crumb screen with handle
- Triple filtration for heavy breading products
- Permafil filter screen in lieu of paper
- Stainless-steel tank cover
- Stainless-steel side splash guard
- Filter tub cover
- Dump station with heat lamp
- 100 pack of filter paper
- 5” swivel casters
- 48” quick disconnect and restraining cable
Specifications
Dimensions
Width
97.5"
Depth
42"
Height
46"
Details
Weight
1305 lb
Flue Temperature
Less than 370º F
Number of Tanks
5
Material
Stainless Steel
Cooking Area Each Tank
17.5” x 18”
Natural Gas Pressure
4" W.C.
Propane Gas Pressure
11" W.C.
Clearances Rear Combustible
6"
Clearances Sides Combustible
6"
Oil Capacity per Tank
75 lb
Gas Connection Size
3/4" NPT
Volt / Phase
115 V, 1 Ph
Amps
7 + 1.5 Per Tank
Total BTU
165000
Item Condition
New
Model
ROYA-RHEF-75-5-DM
Warranty / Certifications
Warranty
2 Years
Prorated Tank Warranty
10 Years
Certification
NSF Certified
Certification
CSA Certified
Certification
ENERGY STAR®
