Koolaire - 30"W 120V Full Cube Air Cooled Ice Machine Head, 515 lbs/day - KDT0500A161
Model Number: MANC-KDT0500A161
Free Shipping Insurance
Free Delivery Over $149*
Some exclusions apply for remote regions and large items.
Extended Holiday Returns
Price Match Guarantee
Have questions? Your phone number is never stored.
120V
This product requires 120V.
NSF Listed
uIus
CE Certified
This product meets the health, safety, and environmental protection standards to be CE certified.
Energy Star Approved
Energy Star certified appliances are built to energy efficient standards, saving you money in the kitchen.
Single Phase
This product requires single phase power, common in commercial establishments and restaurants.
Description
The Koolaire KDT-0500A Ice Machine Head delivers powerful ice production with a daily capacity of up to 515 lbs of full-cube ice, making it ideal for bars, restaurants, and foodservice operations. It produces full cubes (0.875 in x 0.875 in x 0.875 in) that are perfect for cocktails, soft drinks, and bulk cooling without melting quickly. Designed with user convenience in mind, the unit includes a white plastic food zone with easily removable components, making routine cleaning straightforward. Its air-cooled system uses R410A refrigerant and is more cost-effective to operate than water-cooled models. Pair this durable machine with a compatible ice bin or dispenser for a complete solution.
Key Features:
- Produces up to 515 lbs of full-cube ice per day
- AHRI-certified production: 400 lbs/day
- Full-cube size: 0.875 in x 0.875 in x 0.875 in
- Air-cooled condenser for energy efficiency
- Ice formed on chilled evaporator plate using R410A refrigerant
- Toggle switch control with ice thickness float switch and harvest cycle
- White plastic food zone highlights scale or dirt buildup for easy maintenance
- Removable water shield, pump, distribution tube, floats, and trough
- Exterior resists fingerprints and smudges
- Requires ice deflector when paired with a bin (not needed for dispensers)
- Ice bin or dispenser sold separately
- Ideal ambient temperature: 40°F – 110°F
- Water temperature: 40°F – 90°F
- Water pressure: 20 – 80 PSI
- Clearance required: 8 in. top/sides, 5 in. rear
Specifications
Dimensions
Width
30"
Depth
24"
Height
21.5"
Details
Weight
156 lbs
Daily Ice Production
515 lbs
AHRI Certified Production
400 lbs
Ice Type
Full Cube
Cube Size
0.875 in x 0.875 in x 0.875 in
Refrigerant
R410A
Compressor Type
Air Cooled
Voltage
115V
Amperage
12.7 A
Power
5.4 kW
Hertz
60Hz
Phase
1 Ph
Product Type
Ice Machine Head
Ambient Temp Range
40°F – 110°F
Water Temp Range
40°F – 90°F
Water Pressure Range
20 – 80 PSI
Clearance Required
8 in top/sides, 5 in rear
Bin/Dispenser
Sold Separately
Warranty / Certifications
Warranty
3-year Parts & Labor; 5-year Parts & Labor on Evaporator; 5-year Parts & 1-year Labor on Compressor
