American Range - 48" Stainless Steel Radiant Broiler with 26.5" 1 Convection and 1 Storage Base - AR-4RB-CL-SBR
Model Number: GBS-AR-4RB-CL-SBR
Free Shipping Insurance
Free Delivery Over $149*
Some exclusions apply for remote regions and large items.
Extended Holiday Returns
Price Match Guarantee
Have questions? Your phone number is never stored.
Description
American Range, radiant broiler with oven base, (Space Saver Oven 24″), 36″, 48″ wide. Height of unit is 38" Stainless steel front, sides, backriser, shelf and 6" adjustable legs. Removable full width drip pan. Equipped with one 15,000 BTU rated steel burner at every 6" width. Heavy-duty reversible cast-iron top grates. Burner knobs are cool to the touch, high temperature material. One oven: 35,000 BTU/hr. standard oven, 30,000 BTU/hr. for convection or innovection with porcelain interior and inside door panel, standard oven interior measures 26-1/2″W x 22-1/2″D x 13-1/2″H and Space Saver oven interior measures 20″W x 26-1/2″D x 13-1/2″H. Space Saver oven is 27,000 BTU/hr. All oven thermostats adjusts from 250°F to 500°F. All ovens supplied with two racks. Oven door with a spring assisted, counterweight mechanism requiring no adjustment. Rear gas connection and pressure regulator.
STANDARD FEATURES
• Commercial gas range available in 24", 36", 48" wide and 32 1/2" depth.
• Cooking height 38".
• Stainless steel sides, front and 6" deep front landing ledge.
• Adjustable steel legs (casters optional).
• 6" stub back is standard on radiant broiler ranges.
• Two year limited warranty, parts and labor.
RADIANT BROILER
• Equipped with one 15,000 BTU rated steel burner at every 6" width.
• Heavy duty reversible cast-iron top grates.
• Removable full-width drip pan under burner.
• Removable, heavy duty stainless steel pilots for each burner. One
manual gas control valve per burner.
CONVECTION OVEN
• Steel oven burner rated at 30,000 BTU/hr.
• Oven dimensions: 26 1/2"W x 22 1/2"D x 13 1/2"H.
• Two chrome plated oven racks (additional racks optional).
• Chrome rack guides with five tray positions.
• Convection oven fan improves heat transfer for a faster cook time.
• Thermostat ranging from 250°F to 500°F (121°C to 260°C)
Specifications
Dimensions
Width
48"
Depth
32.5"
Height
56"
Oven Width
26.5"
Oven Depth
22.5"
Oven Height
13.5"
Details
Weight
713 Ib
Material
Stainless Steel
Color
Stainless Steel
BTU
150,000
KW
(44)
One Burner Rated BTU/hr.
15,000
Heavy Duty Reversible Cast-Iron Top Grates
Yes
Removable Drip Pan Under Burner
Yes
Steel Oven Burner Rated BTU/hr.
30,000
Thermostat Range
250°F to 500°F (121°C to 260°C).
Two Chrome Plated Oven Racks
Yes
Chrome Rack Guides With Five Tray Positions
Yes
Warranty / Certifications
Warranty
Limited 2 Year Warranty
